ccl_correlation.h File Reference

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Macros
#define	CCL_CORR_LGNDRE   1001
#define	CCL_CORR_FFTLOG   1002
#define	CCL_CORR_BESSEL   1003
#define	CCL_CORR_GG   2001
#define	CCL_CORR_GL   2002
#define	CCL_CORR_LP   2003
#define	CCL_CORR_LM   2004

Functions
CCL_BEGIN_DECLS void	ccl_correlation (ccl_cosmology *cosmo, int n_ell, double *ell, double *cls, int n_theta, double *theta, double *wtheta, int corr_type, int do_taper_cl, double *taper_cl_limits, int flag_method, int *status)
void	ccl_correlation_3d (ccl_cosmology *cosmo, double a, int n_r, double *r, double *xi, int do_taper_pk, double *taper_pk_limits, int *status)

Macro Definition Documentation

#define CCL_CORR_BESSEL   1003

Definition at line 8 of file ccl_correlation.h.

Referenced by __ctest_corrs_analytic_bessel_run(), __ctest_corrs_histo_bessel_run(), and ccl_correlation().

#define CCL_CORR_FFTLOG   1002

Definition at line 7 of file ccl_correlation.h.

Referenced by __ctest_corrs_histo_fftlog_run(), ccl_correlation(), and main().

#define CCL_CORR_GG   2001

Definition at line 9 of file ccl_correlation.h.

Referenced by ccl_compute_legendre_polynomial(), ccl_tracer_corr_bessel(), ccl_tracer_corr_fftlog(), compare_corr(), and main().

#define CCL_CORR_GL   2002

Definition at line 10 of file ccl_correlation.h.

Referenced by ccl_compute_legendre_polynomial(), ccl_tracer_corr_bessel(), ccl_tracer_corr_fftlog(), and compare_corr().

#define CCL_CORR_LGNDRE   1001

Definition at line 6 of file ccl_correlation.h.

Referenced by ccl_correlation().

#define CCL_CORR_LM   2004

Definition at line 12 of file ccl_correlation.h.

Referenced by ccl_tracer_corr_bessel(), ccl_tracer_corr_fftlog(), ccl_tracer_corr_legendre(), and compare_corr().

#define CCL_CORR_LP   2003

Definition at line 11 of file ccl_correlation.h.

Referenced by ccl_tracer_corr_bessel(), ccl_tracer_corr_fftlog(), ccl_tracer_corr_legendre(), and compare_corr().

Function Documentation

CCL_BEGIN_DECLS void ccl_correlation	(	ccl_cosmology *	cosmo,
		int	n_ell,
		double *	ell,
		double *	cls,
		int	n_theta,
		double *	theta,
		double *	wtheta,
		int	corr_type,
		int	do_taper_cl,
		double *	taper_cl_limits,
		int	flag_method,
		int *	status
	)

Computes the correlation function (wrapper)

Parameters

cosmo	:Cosmological parameters
n_ell	: number of multipoles in the input power spectrum
ell	: multipoles at which the power spectrum is evaluated
cls	: input power spectrum
n_theta	: number of output values of the separation angle (theta)
theta	: values of the separation angle in degrees.
wtheta	: the values of the correlation function at the angles above will be returned in this array, which should be pre-allocated
do_taper_cl	:
taper_cl_limits
flag_method	: method to compute the correlation function. Choose between: CCL_CORR_FFTLOG : fast integration with FFTLog CCL_CORR_BESSEL : direct integration over the Bessel function CCL_CORR_LGNDRE : brute-force sum over legendre polynomials
corr_type	: type of correlation function. Choose between: CCL_CORR_GG : spin0-spin0 CCL_CORR_GL : spin0-spin2 CCL_CORR_LP : spin2-spin2 (xi+) CCL_CORR_LM : spin2-spin2 (xi-) Currently supported spin-0 fields are number counts and CMB lensing. The only spin-2 is currently shear.

Definition at line 391 of file ccl_correlation.c.

References ccl_check_status(), CCL_CORR_BESSEL, CCL_CORR_FFTLOG, CCL_CORR_LGNDRE, ccl_cosmology_set_status_message(), CCL_ERROR_INCONSISTENT, ccl_tracer_corr_bessel(), ccl_tracer_corr_fftlog(), and ccl_tracer_corr_legendre().

Referenced by compare_corr(), and main().

{
  switch(flag_method) {
  case CCL_CORR_FFTLOG :
    ccl_tracer_corr_fftlog(cosmo,n_ell,ell,cls,n_theta,theta,wtheta,corr_type,
               do_taper_cl,taper_cl_limits,status);
    break;
  case CCL_CORR_LGNDRE :
    ccl_tracer_corr_legendre(cosmo,n_ell,ell,cls,n_theta,theta,wtheta,corr_type,
                 do_taper_cl,taper_cl_limits,status);
    break;
  case CCL_CORR_BESSEL :
    ccl_tracer_corr_bessel(cosmo,n_ell,ell,cls,n_theta,theta,wtheta,corr_type,status);
    break;
  default :
    *status=CCL_ERROR_INCONSISTENT;
    ccl_cosmology_set_status_message(cosmo, "ccl_correlation.c: ccl_correlation. Unknown algorithm\n");
  }

  ccl_check_status(cosmo,status);
}

void ccl_correlation_3d	(	ccl_cosmology *	cosmo,
		double	a,
		int	n_r,
		double *	r,
		double *	xi,
		int	do_taper_pk,
		double *	taper_pk_limits,
		int *	status
	)

Computes the 3dcorrelation function (wrapper)

Parameters

cosmo	:Cosmological parameters
a	: scale factor
n_r	: number of output values of distance r
r	: values of the distance in Mpc
xi	: the values of the correlation function at the distances above will be returned in this array, which should be pre-allocated
do_taper_pk	: key for tapering (using cosine tapering by default)
taper_pk_limits	limits of tapering

Definition at line 427 of file ccl_correlation.c.

References ccl_check_status(), ccl_cosmology_set_status_message(), CCL_ERROR_MEMORY, ccl_log_spacing(), ccl_nonlin_matter_power(), ccl_spline_eval(), ccl_spline_free(), ccl_spline_init(), ccl_splines, ccl_spline_params::K_MAX, ccl_spline_params::K_MIN, ccl_spline_params::N_K_3DCOR, pk2xi(), and taper_cl().

Referenced by compare_correlation_3d(), and main().

{
  int i,N_ARR;
  double *k_arr,*pk_arr,*r_arr,*xi_arr;

  //number of data points for k and pk array
  N_ARR=(int)(ccl_splines->N_K_3DCOR*log10(ccl_splines->K_MAX/ccl_splines->K_MIN));

  k_arr=ccl_log_spacing(ccl_splines->K_MIN,ccl_splines->K_MAX,N_ARR);
  if(k_arr==NULL) {
    *status=CCL_ERROR_MEMORY;
    ccl_cosmology_set_status_message(cosmo, "ccl_correlation.c: ccl_correlation_3d ran out of memory\n");
    return;
  }

  pk_arr=malloc(N_ARR*sizeof(double));
  if(pk_arr==NULL) {
    free(k_arr);
    *status=CCL_ERROR_MEMORY;
    ccl_cosmology_set_status_message(cosmo, "ccl_correlation.c: ccl_correlation_3d ran out of memory\n");
    return;
  }

  for (i=0; i<N_ARR; i++)
    pk_arr[i] = ccl_nonlin_matter_power(cosmo, k_arr[i], a, status);

  if (do_taper_pk)
    taper_cl(N_ARR,k_arr,pk_arr,taper_pk_limits);

  r_arr=malloc(sizeof(double)*N_ARR);
  if(r_arr==NULL) {
    free(k_arr);
    free(pk_arr);
    *status=CCL_ERROR_MEMORY;
    ccl_cosmology_set_status_message(cosmo, "ccl_correlation.c: ccl_correlation_3d ran out of memory\n");
    return;
  }
  xi_arr=malloc(sizeof(double)*N_ARR);
  if(xi_arr==NULL) {
    free(k_arr); free(pk_arr); free(r_arr);
    *status=CCL_ERROR_MEMORY;
    ccl_cosmology_set_status_message(cosmo, "ccl_correlation.c: ccl_correlation_3d ran out of memory\n");
    return;
  }

  for(i=0;i<N_ARR;i++)
    r_arr[i]=0;

  pk2xi(N_ARR,k_arr,pk_arr,r_arr,xi_arr);

  // Interpolate to output values of r
  SplPar *xi_spl=ccl_spline_init(N_ARR,r_arr,xi_arr,xi_arr[0],0);
  for(i=0;i<n_r;i++)
    xi[i]=ccl_spline_eval(r[i],xi_spl);
  ccl_spline_free(xi_spl);

  free(k_arr); free(pk_arr);
  free(r_arr); free(xi_arr);

  ccl_check_status(cosmo,status);

  return;
}
